Top quality stainless steel/Nickel alloy,Titanium alloy tube ,Centrifugal
casting Tube, seamless or welded pipe produce and supply random length
Detailed pipes we could supply:
| seamless pipe | Round pipe | Out diameter: | 1/8"-24"(6mm-630mm). |
| Wall thickness: | ANSI 5S-160S (0.9mm-100mm) |
| Square pipe | | 20x20x-200x200:thickness2-50mm |
| rectangular pipe | | 10x20-150x100,thickness:2-50mm |
| Hex pipe | Out hex or Round
Inside bore or hex | Flat to flat 16-70mm,
thickness:3-10mm
With drawing |
| Oval tube | | With drawing |
| Welded type | Round pipe | Out diameter: | OD6-2500MM |
| Wall thickness: | Thickness:1-50mm |
| Square pipe | | 10x10-200x200,thickness1-3mm |
| Rectangular pipe | | 10x20-150x100,thickness:1-3mm |
| Oval tube | | As drawings |
| Manufacture Standard: | ASTMA213/312/269/511/789/790,
GOST9940/9941,DIN17456/17458/EN10206/17440
JIS3459/3463,GB13296/14976/9948/5310/8142/8143 |
| stainless steel | TP304,304L,304H,304N,316,316L,316Ti,317L,310S,321,321H,347H,S31803,
S32750,347,330,825,904L,
12X18H9,08X18H10,03X18H11,08X18H10T,20X25H20C2,08X17H13M2T,08X18H12E
1.4301, 1.4306, 1.4401, 1.4404, 1.4435, 1.4541, 1.4571, 1.4563,
1.4462, 1.4845,
SUS304, SUS304L, SUS316, SUS316L, SUS321, SUS310S etc. |
| Nickel alloy | Hastelloy: UNS N10001, N10665, N10675, N06455, N06022, N10276, N06200, N06035, N06030, N06635, N10003, N06002, R30188, N06230,
R30556 Inconel: UNS N06600, N06601, N06617, N06625, N07718, N07750,
N08800, N08810, N08811, N08825, N09925, N08926 Monel: UNS N04400, N05500 Precipitation-hardening Steels: 254SMO/S31254, 17-4PH, 17-7PH,
15-7PH Nickel: N4/UNS N02201, N6/UNS N02200 |
| Titanium and titanium alloy | GR1,GR2,GR5,GR7,GR9,GR12 |
| Centrifugal casting tube | 57-1200mm OD |
| Cobalt alloy pipe | customed sizes |
| Process methods: | cold drawn, cold rolling,welded |
| Surface & Delivery condition: | Solution annealed and pickled, grey white (polished),with plain
ends/bevel edges ends,Hairline |
| Length: | Max25 meters |
| Packing: | in seaworthy wooden cases or in bundles |
| Min order quantity: | 0.5 ton each size for common steel. |
| Delivery date: | soonest or discussible |
| Certificates: | ISO9001:2000 quality system and Mill test Certificate supplied |
Our Products Rang:
Steel pipe,Stainless Steel bars, Pipes & Tubes - Welded, Seamless
Duplex Steel Pipe And Fittings
Fasteners
Wire rope and rope fittings
Nickel Alloy Steel Pipe And Fittings
Titanium Pipe and Titanium Bars,Flanges, Fitting
Centrifugal casting tube
Material supply
Stainless Steels - 304, 304H, 304L, 316, 316H, 316L, 321, 321H,
347, 310, 410, 410S, 904L etc
Duplex Steel - UNS 31803 (Duplex), UNS 32750 / UNS 32760 (Super
Duplex)/2205 etc
Nickel Alloy Steel- Alloy B/ N10001, Alloy B2/N10665, Alloy
B3/N10675, Alloy C4/N06455, Alloy C22/N06022, Alloy C276/N10276,
Alloy C2000/N06200, Alloy G35/N06035, Alloy G30/N06030, Alloy
S/N06635, Alloy N/N10003, Alloy X/N06002, Alloy 188/R30188, Alloy
230/N06230, Alloy 556/R30556 Alloy 600/ N06600, Alloy 601/N06601,
Alloy 617/N06617, Alloy 625/N06625, Alloy 718/N07718, Alloy
X750/N07750, Alloy 800/N08800, Alloy 800H/N08810, Alloy
800HT/N08811, Alloy 825/N08825, Alloy 925/N09925, Alloy
926/N08926/Alloy 400/ N04400, Alloy K500/N05500
Precipitation-hardening Steels- 254SMO/S31254, 17-4PH, 17-7PH,
15-7PH
Nickel: N4/UNS N02201, N6/UNS N02200
Titanium :TA1 TA2 TC4, ASTM B337,ASTM B338,ASTM B861,ASTM B862
Cobalt alloy:umco50
Centrifugal casting pipes,reformer tube,radiant tube,heat resistant
steel etc
General Require of ASTMA213/M
standard
Items | ASTM A213/A213M |
Steel grade
| TP301 TP304L
TP316 TP316L
TP317 TP310L
TP347 TP310S
TP347H△ TP310H *
TP309H* TP321H△ |
| Rp0.2(Mpa) | ≥170 ; ≥205 |
| Rm(Mpa) | ≥485 ; ≥515 |
| A(%) | ≥35 |
| Flatten experiment(mm) | H=1.09t/(0.09+t/D) |
| flaring test | Inside diameter 21-68% |
| Grain size | "*"," △ "ASTM E112/ "△ "7#or above7#"*"6#or above6# |
hydrostatic test (Mpa) | D | Pmax |
P=220.6t/D |
| <25.4 | 7 | |
| 25.4-<38.1 | 10 | |
| 38.1-<50.8 | 14 | |
| 50.8-<76.2 | 17 | |
| 76.2-<127 | 24 | |
| ≥127 | 31 | |
Crystal
corrosion test | ASTM A262 |
| nondestructive inspection | ASTM E213 E309 E426 |
| Heat treatment (solid solution) | required |
Out-diameter tolerance(mm) | OD | TOLERANCE |
| <25.4 | ±0.10 |
| 25.4-≤38.1 | ±0.15 |
| >38.1-<50.8 | ±0.20 |
| 50.8-<63.5 | ±0.25 |
| 63.5-<76.2 | ±0.30 |
| 76.2-≤101.6 | ±0.38 |
| >101.6-≤190.5 | ±0.38/-0.64 |
| >190.5-≤228.6 | ±0.38/-1.14 |
Thickness tolerance(mm) | OD | TOLERANCE |
| ≤38.1 | +20%-0 |
| >38.1 | +22%-0 |
| straightness(mm/m) | REASONABLE |
| HARDNESS | HRB<90 |
Parts of workshop:
Quality assure of stainless steel pipe tube:
1)Basic guarantee:Raw material guarantee,we use the Tsingshan Brand
raw material,the quality is good,adding we use the spectrum
direct-reading test,our professional
workers &equipments,we could guarantee the tubes is right of
the clients' needs.
2)Process control:follow the process chart + our professional
workers' care
3)Inspection& Test:
Direct-reading Spectrum Instrument analytic for chemical
composition, Yield Strength, Tensile Strength, Elongation, Hardness
Test, Flattening Test,Flaring Test, Eddy Current Test, Ultrasonic
Test, Hydrostatic Test, Corrosion Test, etc
Features of stainless steel tubes:
1)characters such as Safety, health, environmental protection
2)economy applicable, good surface
3)the resistant to corrosion
4)less weight than bars, thickness and out diameter so variously
5)easy cutting, huge deformation
6)tensile strengthen and good be flexible etc.
Applications & Usage of seamless stainless,nickel,titanium pipe:
as Line pipe, boiler pipe, mechanical structure, hydraulic prop
pipe, gas pipe, geological pipe, chemical pipe
(high pressure chemical fertilizer pipe, oil cracking pipe) and
tube for ships, etcdecoration,building,construction,water
pipe,petroleum, chemical industry, chemical fiber, smelt, medical
machinery,paper making,Heat preservation and refrigeration,
mechanical equipment, food, electricity, water
conservancy,architecture, aerospace, navigation shipbuilding,
environmental protection and boiler heat exchanger
Package and delivery:
Welcome to contact us for pipe inquiry, One stop service for all
pipes
One address: songalloy.en.made-in-china.com, service forever!
